Uber Data Analytics

I worked on this project to get an understanding on what exactly is involved in Data Engineering. I found this very helpful “Uber Data Analytics” youtube tutorial that went through all the steps from beginning to end of Extract, Transform, and Load of this Uber dataset. I still need to add in the steps to this post, but for now is an outline of what I completed.

import pandas as pd

df = pd.read_csv("data/uber_data.csv")

df.head()

	VendorID	tpep_pickup_datetime	tpep_dropoff_datetime	passenger_count	trip_distance	pickup_longitude	pickup_latitude	RatecodeID	store_and_fwd_flag	dropoff_longitude	dropoff_latitude	payment_type	fare_amount	extra	mta_tax	tip_amount	tolls_amount	improvement_surcharge	total_amount
0	1	2016-03-01 00:00:00	2016-03-01 00:07:55	1	2.50	-73.976746	40.765152	1	N	-74.004265	40.746128	1	9.0	0.5	0.5	2.05	0.00	0.3	12.35
1	1	2016-03-01 00:00:00	2016-03-01 00:11:06	1	2.90	-73.983482	40.767925	1	N	-74.005943	40.733166	1	11.0	0.5	0.5	3.05	0.00	0.3	15.35
2	2	2016-03-01 00:00:00	2016-03-01 00:31:06	2	19.98	-73.782021	40.644810	1	N	-73.974541	40.675770	1	54.5	0.5	0.5	8.00	0.00	0.3	63.80
3	2	2016-03-01 00:00:00	2016-03-01 00:00:00	3	10.78	-73.863419	40.769814	1	N	-73.969650	40.757767	1	31.5	0.0	0.5	3.78	5.54	0.3	41.62
4	2	2016-03-01 00:00:00	2016-03-01 00:00:00	5	30.43	-73.971741	40.792183	3	N	-74.177170	40.695053	1	98.0	0.0	0.0	0.00	15.50	0.3	113.80

Created a Data Model in Lucidchart

#check to see if the date time is in the proper format
df.info()

    <class 'pandas.core.frame.DataFrame'>
    RangeIndex: 100000 entries, 0 to 99999
    Data columns (total 19 columns):
     #   Column                 Non-Null Count   Dtype
    ---  ------                 --------------   -----
     0   VendorID               100000 non-null  int64
     1   tpep_pickup_datetime   100000 non-null  object
     2   tpep_dropoff_datetime  100000 non-null  object
     3   passenger_count        100000 non-null  int64
     4   trip_distance          100000 non-null  float64
     5   pickup_longitude       100000 non-null  float64
     6   pickup_latitude        100000 non-null  float64
     7   RatecodeID             100000 non-null  int64
     8   store_and_fwd_flag     100000 non-null  object
     9   dropoff_longitude      100000 non-null  float64
     10  dropoff_latitude       100000 non-null  float64
     11  payment_type           100000 non-null  int64
     12  fare_amount            100000 non-null  float64
     13  extra                  100000 non-null  float64
     14  mta_tax                100000 non-null  float64
     15  tip_amount             100000 non-null  float64
     16  tolls_amount           100000 non-null  float64
     17  improvement_surcharge  100000 non-null  float64
     18  total_amount           100000 non-null  float64
    dtypes: float64(12), int64(4), object(3)
    memory usage: 14.5+ MB

#the tpep_pickup and tpep_dropoff are of type object and need to change to date type
df['tpep_pickup_datetime'] = pd.to_datetime(df['tpep_pickup_datetime'])
df['tpep_dropoff_datetime'] = pd.to_datetime(df['tpep_dropoff_datetime'])

df = df.drop_duplicates().reset_index(drop=True)
df['trip_id'] = df.index

df.info()

    <class 'pandas.core.frame.DataFrame'>
    RangeIndex: 100000 entries, 0 to 99999
    Data columns (total 20 columns):
     #   Column                 Non-Null Count   Dtype
    ---  ------                 --------------   -----
     0   VendorID               100000 non-null  int64
     1   tpep_pickup_datetime   100000 non-null  datetime64[ns]
     2   tpep_dropoff_datetime  100000 non-null  datetime64[ns]
     3   passenger_count        100000 non-null  int64
     4   trip_distance          100000 non-null  float64
     5   pickup_longitude       100000 non-null  float64
     6   pickup_latitude        100000 non-null  float64
     7   RatecodeID             100000 non-null  int64
     8   store_and_fwd_flag     100000 non-null  object
     9   dropoff_longitude      100000 non-null  float64
     10  dropoff_latitude       100000 non-null  float64
     11  payment_type           100000 non-null  int64
     12  fare_amount            100000 non-null  float64
     13  extra                  100000 non-null  float64
     14  mta_tax                100000 non-null  float64
     15  tip_amount             100000 non-null  float64
     16  tolls_amount           100000 non-null  float64
     17  improvement_surcharge  100000 non-null  float64
     18  total_amount           100000 non-null  float64
     19  trip_id                100000 non-null  int64
    dtypes: datetime64[ns](2), float64(12), int64(5), object(1)
    memory usage: 15.3+ MB

#We want to drop the duplicates and reset the index
datetime_dim = df[['tpep_pickup_datetime','tpep_dropoff_datetime']].reset_index(drop=True)

datetime_dim['tpep_pickup_datetime'] = datetime_dim['tpep_pickup_datetime']
datetime_dim['pick_hour'] = datetime_dim['tpep_pickup_datetime'].dt.hour
datetime_dim['pick_day'] = datetime_dim['tpep_pickup_datetime'].dt.day
datetime_dim['pick_month'] = datetime_dim['tpep_pickup_datetime'].dt.month
datetime_dim['pick_year'] = datetime_dim['tpep_pickup_datetime'].dt.year
datetime_dim['pick_weekday'] = datetime_dim['tpep_pickup_datetime'].dt.weekday

datetime_dim['tpep_dropoff_datetime'] = datetime_dim['tpep_dropoff_datetime']
datetime_dim['drop_hour'] = datetime_dim['tpep_dropoff_datetime'].dt.hour
datetime_dim['drop_day'] = datetime_dim['tpep_dropoff_datetime'].dt.day
datetime_dim['drop_month'] = datetime_dim['tpep_dropoff_datetime'].dt.month
datetime_dim['drop_year'] = datetime_dim['tpep_dropoff_datetime'].dt.year
datetime_dim['drop_weekday'] = datetime_dim['tpep_dropoff_datetime'].dt.weekday


datetime_dim['datetime_id'] = datetime_dim.index

# datetime_dim = datetime_dim.rename(columns={'tpep_pickup_datetime': 'datetime_id'}).reset_index(drop=True)
datetime_dim = datetime_dim[['datetime_id', 'tpep_pickup_datetime', 'pick_hour', 'pick_day', 'pick_month', 'pick_year', 'pick_weekday',
                             'tpep_dropoff_datetime', 'drop_hour', 'drop_day', 'drop_month', 'drop_year', 'drop_weekday']]
#
datetime_dim

	datetime_id	tpep_pickup_datetime	pick_hour	pick_day	pick_month	pick_year	pick_weekday	tpep_dropoff_datetime	drop_hour	drop_day	drop_month	drop_year	drop_weekday
0	0	2016-03-01 00:00:00	0	1	3	2016	1	2016-03-01 00:07:55	0	1	3	2016	1
1	1	2016-03-01 00:00:00	0	1	3	2016	1	2016-03-01 00:11:06	0	1	3	2016	1
2	2	2016-03-01 00:00:00	0	1	3	2016	1	2016-03-01 00:31:06	0	1	3	2016	1
3	3	2016-03-01 00:00:00	0	1	3	2016	1	2016-03-01 00:00:00	0	1	3	2016	1
4	4	2016-03-01 00:00:00	0	1	3	2016	1	2016-03-01 00:00:00	0	1	3	2016	1
...	...	...	...	...	...	...	...	...	...	...	...	...	...
99995	99995	2016-03-01 06:17:10	6	1	3	2016	1	2016-03-01 06:22:15	6	1	3	2016	1
99996	99996	2016-03-01 06:17:10	6	1	3	2016	1	2016-03-01 06:32:41	6	1	3	2016	1
99997	99997	2016-03-01 06:17:10	6	1	3	2016	1	2016-03-01 06:37:23	6	1	3	2016	1
99998	99998	2016-03-01 06:17:10	6	1	3	2016	1	2016-03-01 06:22:09	6	1	3	2016	1
99999	99999	2016-03-01 06:17:11	6	1	3	2016	1	2016-03-01 06:22:00	6	1	3	2016	1

100000 rows × 13 columns

passenger_count_dim = df[['passenger_count']].reset_index(drop=True)
passenger_count_dim['passenger_count_id'] = passenger_count_dim.index
passenger_count_dim = passenger_count_dim[['passenger_count_id','passenger_count']]

trip_distance_dim = df[['trip_distance']].reset_index(drop=True)
trip_distance_dim['trip_distance_id'] = trip_distance_dim.index
trip_distance_dim = trip_distance_dim[['trip_distance_id','trip_distance']]

rate_code_type = {
    1:"Standard rate",
    2:"JFK",
    3:"Newark",
    4:"Nassau or Westchester",
    5:"Negotiated fare",
    6:"Group ride"
}

rate_code_dim = df[['RatecodeID']].reset_index(drop=True)
rate_code_dim['rate_code_id'] = rate_code_dim.index
rate_code_dim['rate_code_name'] = rate_code_dim['RatecodeID'].map(rate_code_type)
rate_code_dim = rate_code_dim[['rate_code_id','RatecodeID','rate_code_name']]

rate_code_dim.head()

	rate_code_id	RatecodeID	rate_code_name
0	0	1	Standard rate
1	1	1	Standard rate
2	2	1	Standard rate
3	3	1	Standard rate
4	4	3	Newark

pickup_location_dim = df[['pickup_longitude', 'pickup_latitude']].reset_index(drop=True)
pickup_location_dim['pickup_location_id'] = pickup_location_dim.index
pickup_location_dim = pickup_location_dim[['pickup_location_id','pickup_latitude','pickup_longitude']]


dropoff_location_dim = df[['dropoff_longitude', 'dropoff_latitude']].reset_index(drop=True)
dropoff_location_dim['dropoff_location_id'] = dropoff_location_dim.index
dropoff_location_dim = dropoff_location_dim[['dropoff_location_id','dropoff_latitude','dropoff_longitude']]

payment_type_name = {
    1:"Credit card",
    2:"Cash",
    3:"No charge",
    4:"Dispute",
    5:"Unknown",
    6:"Voided trip"
}
payment_type_dim = df[['payment_type']].reset_index(drop=True)
payment_type_dim['payment_type_id'] = payment_type_dim.index
payment_type_dim['payment_type_name'] = payment_type_dim['payment_type'].map(payment_type_name)
payment_type_dim = payment_type_dim[['payment_type_id','payment_type','payment_type_name']]

fact_table = df.merge(passenger_count_dim, left_on='trip_id', right_on='passenger_count_id') \
             .merge(trip_distance_dim, left_on='trip_id', right_on='trip_distance_id') \
             .merge(rate_code_dim, left_on='trip_id', right_on='rate_code_id') \
             .merge(pickup_location_dim, left_on='trip_id', right_on='pickup_location_id') \
             .merge(dropoff_location_dim, left_on='trip_id', right_on='dropoff_location_id')\
             .merge(datetime_dim, left_on='trip_id', right_on='datetime_id') \
             .merge(payment_type_dim, left_on='trip_id', right_on='payment_type_id') \
             [['trip_id','VendorID', 'datetime_id', 'passenger_count_id',
               'trip_distance_id', 'rate_code_id', 'store_and_fwd_flag', 'pickup_location_id', 'dropoff_location_id',
               'payment_type_id', 'fare_amount', 'extra', 'mta_tax', 'tip_amount', 'tolls_amount',
               'improvement_surcharge', 'total_amount']]


payment_type_dim.columns

Index(['payment_type_id', 'payment_type', 'payment_type_name'], dtype='object')

fact_table.columns

Index(['trip_id', 'VendorID', 'datetime_id', 'passenger_count_id',
       'trip_distance_id', 'rate_code_id', 'store_and_fwd_flag',
       'pickup_location_id', 'dropoff_location_id', 'payment_type_id',
       'fare_amount', 'extra', 'mta_tax', 'tip_amount', 'tolls_amount',
       'improvement_surcharge', 'total_amount'],
      dtype='object')

Created a Data Model in Lucidchart#

Created a Data Model in Lucidchart
